Machines, Tools & Accessories | Grinding Machines


BGV-125AV   (Blastrac)

Light-weight heavy-duty handheld grinder for the preparation of horizontal & vertical surfaces. Used for various applications depending on the grinding wheel. Anti-vibration handle. Can be connected to the BDC-1114 dust collector (with dust hose 35 mm diameter).
Single phase motor, 230 V ~ 50 Hz, 1.3 Kw

Working width (wheel) diameter: 125 mm
Working speed: 11000 rpm
Weight: 3.2 Kg

BGV-180AVO   (Blastrac)

Large heavy-duty handheld grinder for the preparation of horizontal & vertical surfaces. Used for various applications depending on the grinding wheel. Anti-vibration handle. Can be connected to the BDC-1114 or BDC-1220 dust collectors (with dust hose 35 or 51 mm diameter).
Single phase motor, 230 V ~ 50 Hz, 2.6 Kw

Working width (wheel) diameter: 180 mm
Working speed: 6600 rpm
Weight: 5.4 Kg

CUP WHEELS   (Blastrac)

Grinding wheels to be used on handheld grinders. Blue diamond wheels are used to grind soft surfaces. Green diamond wheels are used to grind medium-hard surfaces. Yellow polycrystalline diamond (PCD) wheels are used to remove coatings (epoxy or polyurethane paints in thicknesses up to 2 mm), asphalt or glue residues...

Diameters: 125 & 180 mm

BGS-250MKII   (Blastrac)

Single-head grinding machines for the preparation of small to medium surfaces. Various applications depending on the grinding disk. Can be connected to the BDC-1220 or BDC-1330 dust collectors (with dust hose 51 mm diameter).
Single-phase or three-phase motor, 230 V ~ 50 Hz, 2.2 or 3 Kw

Working width (disk) diameter: 250 mm
Working speed: 1440 or 1510 rpm
Weight: 58 Kg

BG-250E   (Blastrac)

Single-head grinding machine for heavy-duty preparation of small to medium surfaces. Comfortable to use, with low vibrations. Various applications depending on the grinding disk. Can be connected to the BDC-1220 or BDC-1330 dust collectors (with dust hose 76 mm diameter).
Three-phase motor, 400 V ~ 50 Hz, 5.5 Kw

Working width (disk) diameter: 250 mm
Working speed: 1920 rpm
Weight: 146 Kg
